Lightweight structure/high power density: Compared with previous series of products, the E600&E610 have a lighter and more refined structure

Parallel installation saves space and resources: Compared with traditional frequency converter products, the E600&E610 supports seamless parallel installation, occupying a smaller area and effectively improving the efficiency of cabinet use

Strengthening the three protective coatings: enhancing the PCB board coating, innovative cooling design, ensuring the healthy and stable product life cycle, improving the environmental resistance of the single board, and comprehensively improving the single board protection ability;

Independent air duct: With independent air duct design, the air path is short, the resistance is small, and there is less air leakage. The heat dissipation effect is greatly improved, effectively reducing the temperature rise of the frequency converter and ensuring more stable and reliable operation;

Operating temperature: Normal operation between -10 ℃ and+60 ℃ (with a 10% reduction in temperature for every+5 ℃ between 50-60 ℃).

Plug and unplug terminal free wiring design: Large capacity wiring, can adapt to various wiring requirements, screw free design, save crimping terminals, and save operation time;

Shared DC energy-saving: DC shared bus mode, where energy is shared among multiple devices, saving energy while reducing the demand for braking components and saving costs;

Upper computer/external keyboard: Combined with the Hechuan frequency converter upper computer, it simplifies the frequency converter debugging steps, saves debugging time, and the parameter upload and download function is more convenient to save parameter settings; LED/LCD external keyboard, can be installed with holes in the cabinet door, and the operation status of the frequency converter can be observed without opening the cabinet door

Bluetooth function and IoT module: Supports Bluetooth and wireless networking, making it more convenient and efficient to network devices within the same area. The E610 model has built-in CANopen communication, which allows for CANopen communication with upper computers such as PLCs without the need for additional communication cards

Remote IO function: The sensor signals of the device can be directly connected to the frequency converter and uploaded to the PLC or upper computer through communication to achieve remote IO function

Wide voltage range: supports AC380V~AC480V (-15%~10%), with a wide voltage input range to meet power supply scenarios under different working conditions

One machine with multiple functions: built-in industry-specific functions to meet the needs of multiple industries and devices
